Ball Valve For Cold Storage

SANHENG suppliers SBV(E) Ball Valve For Cold Storage . It’s an important component used in refrigeration systems to control the flow and temperature of the system. Copper ball valves have better corrosion resistance and sealing performance, so they are more suitable for use in low temperature environments. Ball Valve For Cold Storage used in cold storage have good pressure resistance and anti-freezing performance. The internal structure of the ball valve is designed to allow fluid to pass smoothly through the valve while maintaining stable pressure and temperature control.

Send Inquiry

Product Description


SANHENG is a China-based manufacturer of SBV(E) Ball Valve For Cold Storage. The valve utilises a combination of designs to improve its sealing performance and eliminate traditional leakage problems. It has several key features:

1. the use of segmented stem and composite seal combined design, this design has the advantage of providing better mechanical strength and durability, but also enhanced sealing effect.

2. the valve body is sealed by means of threaded and welded connections, which ensures a more reliable sealing effect and eliminates the risk of leakage commonly found in traditional ball valves.

3. Ball Valve For Cold Storage also equipped with an automatic compression type internal sealing mechanism, which is able to dynamically adjust and control the internal sealing member during use, so that it always maintains the optimal state, thus effectively reducing the occurrence of internal leakage.

4. In order to further improve the sealing and reliability of the Ball Valve For Cold Storage, the designers have taken into full consideration the influence of various factors, including temperature, pressure, flow rate, etc., in order to ensure the stable operation of the valve body.

·Selection of SBV(E) Ball Valve For Cold Storage

Ball Valve For Cold Storage is a commonly used fluid control valve, and their advantages include simple construction, small size, light weight, easy operation, and low maintenance costs. When selecting a Ball Valve For Cold Storage, there are several key differences to consider:

1)Temperature Range

When choosing a Ball Valve For Cold Storage, you need to consider the temperature range it can withstand. Different ball valve materials have different temperature resistance, for example, metal materials usually have a higher temperature resistance, while plastic materials have a lower temperature resistance. In high temperature environments, a ball valve with a higher temperature resistance should be selected, while in low temperature environments, a Ball Valve For Cold Storage with a lower temperature resistance should be selected.

2)Pressure Rating

Another important parameter of a Ball Valve For Cold Storage is the pressure rating it can withstand. In high pressure environments, a ball valve with a higher pressure rating is required to ensure that it can withstand the impact of high pressure liquids. Similarly, in low pressure environments, a Ball Valve with a lower pressure rating should be selected to avoid damage to the ball valve due to excessive pressure.

MODEL CONNECTION  SIZE KV DATA (m³/h)
In. Mm.
SBV(E)-6S 1/4” 6.35 2.0
SBV(E)-10S 3/8” 9.52 5.7
SBV(E)-12S 1/2” 12.9 10.6
SBV(E)-16S 5/8” 15.8 14.1
SBV(E)-19S 3/4” 19.2 20.4
SBV(E)-22S 7/8” 22.2 28.2
SBV(E)-28S 1-1/8” 28.5 52.0
SBV(E)-35S 1-3/8” 34.9 80.9
SBV(E)-42S 1-5/8” 41.3 121
SBV(E)-54S 2-1/8” 54.0 225
SBV(E)-67S 2-5/8” 66.7 246
SBV(E)-79S 3-1/8” 79.4 223

Product Details


Hot Tags: Ball Valve For Cold Storage, China, Manufacturer, Supplier, Factory, Cheap, Discount, Quality, Price List
